Mean Well 24vDC 10A power supply

New Core Product

$145.00

Hospital Grade Plug End

YES (+$7.50)

Qty

The Mean-Well HLG-240H-24A power supply is a highly reliable 24Vdc 240W power supply with a single 2 wire 24Vdc output.

Features:

**Please note: based on availability these may be substituted with HLG-240H-24 power supplies.

Power Input / Output
Power Input	85-264vAC, 120-370vDC
Power Consumption (Typ.)	4A @ 115vAC, 2A @ 230vAC
Power Output	24Vdc
Max. Output Current	10A
Power Supply Specifications
Power Factor (Typ.)	PF>0.98 / 115VAC at full load , PF>0.95 / 230VAC Please refer to "POWER FACTOR (PF) CHARACTERISTIC" section in Specification Sheet for full details
Overload Protection	Hiccup mode @ 105-135% rated output, recovers automatically after fault condition is removed
Over Voltage Protection	Shut down on over voltage, re-power on to recover
Over Temp. Protection	Shut down on overtemp, re-power on to recover
Connector and Adapter Specifcations
Output Connector	Bare Wires
Certifications
Electrical Certifications	UL8750(type”HL”) CSA C22.2 No. 250.0-08
Core Product
Inventory Core Product	YES
General
Additional Notes	Input connector not included
