Cine-Value 3.81mm Pluggable Header Connectors

CineValue 3.81mm Pluggable Headers
New Core Product
Cine-Value 3.81mm Pluggable Header Connectors
  • Brand: Project SSSHH
  • Model: CV-CONN-3.81
  • Ship Weight: 3.36g
  • Ship Dimensions: 18.30mm x 10.16mm x 15.00mm

Available Options

The smaller cousin of the 5.08mm Cine-Value Pluggable Connectors are 3.81mm pitch and rated at 8a per connection.

These connectors have excellent screw retention, allowing the gates to be open during shipping. This means you won't have to unscrew all of the gates before you put wire into these connectors. This is a valuable time saver!

Quality construction and fully marked 8A UL approval make these a serious contender for those that want to have a smaller connector on their Class 2 wiring. These are compatible with our PRO-L16 fixtures.

These are stocked in 3 conductor and 5 conductor in both male and female pluggable screw terminal configurations (for other types, sizes and configurations please contact us for availability.)


3 conductor


5 conductor


Connector and Adapter Specifcations
Number of Positions3 or 5 positions
Connector GenderFemale and Male available
Conductor Sizes30-14awg (0.2-1.5mm2)
Nominal Current8a
Rated Voltage160V
Flammability RatingV0 to UL 94 standard
Screw Type2mm Slot
Torque Value0.2-0.25 Nm
Wire Stripping Length7mm (0.28in)
Shipping Dimensions and Weights
Weight (Typ.)Varies
Electrical Certifications

cRUus (File Number: E330768)

Core Product
Inventory Core ProductYES
